Alpine RS-SB12 Single 12” R-Series Shallow Preloaded Subwoofer Enclosure

ALPINE RS-SB12

Single 12” R-Series Shallow Preloaded Subwoofer Enclosure

PRODUCT OVERVIEW

With an ultra-shallow enclosure design and powerful sound output, the R-Series Shallow Preloaded Subwoofer Enclosures give you the best of both worlds in size and sound.

DESIGNED FOR TIGHT SPACES

Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow Preloaded Subwoofer Enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.

EXTREME OUTPUT

Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series Subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series Shallow Subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.

FEATURES

•Optimal sealed cabinet quality

•Aluminum Dust Cap

•Neodymium Magnet

•Alpine Gen2 DD Linear Magnetic Circuit

•CARB compliant ¾” MDF construction

•Premium Alpine embroidered black carpet

•Alpine-branded terminal cup

•Pre-installed steel mesh grille

•Includes a 12” R-Shallow Subwoofer (RS-W12D4)

•Rubber, modular stackable foot design

What's in the Box:

•Sealed Cabinet with (1) 12” R-Series Shallow Subwoofer

•Mounting Brackets

•Owner’s Manual

•Warranty Information

•Online product registration information

TECH SPECS

Dimensions: 26.5” W x 5.25” H x 17” D

600W RMS Power Handling

Frequency response: 26Hz – 200Hz

Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)

Nominal Impedance: 2Ω

Voice Coil: 4”(101.6mm)
