IK Multimedia iLoud MM Pro Reference Monitor (Single)

A mobile feast for your ears

iLoud MM Pro makes critical mixing possible in any environment, whether at home, on the go, or in the field. Elegantly combining the latest tech and design, this portable powerhouse of the iLoud family delivers the exact ARC room calibration and feature set as iLoud MTM MKII and Precision but in an ultra-compact format.

MM Pro represents the mobile sweet spot between iLoud Micro Monitors and iLoud MTM MKII, offering even the most demanding musicians and sound engineers the tools they need to work anywhere without sacrifice.

Portable and powerful

MM Pro is palm-sized and weighs just 3 pounds. It packs a 50 W class D high-efficiency amplifier and high-quality custom-made drivers. With a full-band maximum SPL of over 95 dB per speaker, it easily outperforms monitors twice its size. The exclusive 3" high-performance long-throw woofer and the 1" silk dome tweeter are engineered and manufactured under strict tolerances to make all units sound identical, ideal for equipping multiple locations.

The latest tech inside

Advanced DSP handles all MM Pro's core audio functions using audiophile-grade high-resolution algorithms for cross-over, filtering, time alignment, equalization, dynamic control and auto-calibration. A/D conversion is at today's highest standards, maintaining a pristine and pure signal from the analog input to your ears. The results are a listening experience unmatched by any other speaker in its weight class.

Studio quality anywhere

You'll enjoy transparent, true-to-life sound without hype or coloration from MM Pro's ultra-flat frequency range of 50 Hz to 20 kHz + 2 dB (42 Hz to 22 kHz @ -10 dB). Bass frequencies are solid and firm with no booms or tails. Highs are transparent, defined and neutral. You'll hear the audio precisely for what it is with less ear fatigue, even during long listening sessions. All these features will enable you to make the right mixing decisions much faster.

Built-in ARC correction

Compact studio monitors are used everywhere, from quality control rooms to mobile setups, but each space is different. iLoud MM Pro features built-in ARC room correction to tune its frequency response in any room or placement automatically. The optional ARC MEMS measurement microphone only takes 2 minutes to calibrate each monitor and dramatically improve the listening experience. You can easily switch between the standard settings and the ARC calibration to hear the difference.

X-MONITOR integration

Inherited from IK's flagship iLoud Precisions, iLoud MM Pro offers full X-MONITOR integration. This exclusive, award-winning software gives you complete control over every speaker element beyond the rear controls. Also, it allows for precise delay compensation between units for improved stereo imaging.

A single solution to A/B mixes

In addition, X-MONITOR allows you to switch between virtual monitoring voices, emulating the frequency and phase response of other top studio monitors and reference systems. With four buttons to quickly recall various voices, X-MONITOR with MM Pro becomes an entire reference monitoring system in one portable solution.

One size fits all

Thanks to the retractable rubber feet and the 3/8" threaded insert adapted from the original iLoud Micros, iLoud MM Pro can be installed everywhere in minutes. Set them on a desktop, mount them on mic stands or use the optional iLoud wall mounts to precisely fit your space and needs.

Wherever mixing matters, iLoud MM Pro makes the perfect mix possible.

Features* Ultra-accurate, flat and detailed sound for mixes that translate perfectly - from anywhere

* Legendary iLoud "physics-defying" sound: bass extension to 42 Hz and stunning 109 dB max SPL

* Built-in ARC calibration instantly tunes to any room (mic sold separately)

* Includes X-Monitor software to virtually audition your music on different playback systems

* Compact, lightweight and backpack-friendly with integrated stand to set up instantly anywhere

Specifications- Type: 2-Way bi-amped, digitally controlled compact studio monitor

- LF driver: 3" composite cellulose fiber, custom-made mid-woofer

- HF driver: 1" low-distortion silk-dome tweeter

- Acoustic design: DSP-tuned bass reflex

- Number of amps per speaker: 2

- Amplifier type: High-efficiency Class-D

- Total power: 50 W RMS

- LF power: 30 W RMS

- HF power: 20 W RMS

- Crossover type: Digital, Linear Phase

- Crossover frequency: 2.5 kHz

- Frequency response: 50 Hz to 20 kHz + 2dB, 42 Hz to 22 kHz @ -10dB

- Phase response: System remains coherent within +/-30[degree] from 500 Hz to 20kHz

- Sensitivity (XLR): -10 dBu signal generates 90 dB SPL @ 1m

- Sensitivity (RCA): -22 dBu signal generates 90 dB SPL @ 1m

- Continuous max SPL: 94 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

- Peak SPL: 107.3 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

- Peak SPL: 109.3 dB (half space, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

- Placement setup: Manual switches for - - LF Extension, LF trim, HF trim, Desk position

- LF extension switch: Sets -3 dB point of the frequency response at 50 or 80 Hz (LFE)

- LF switch: Low shelf, +2 dB or -3 dB from 100 Hz down

- HF switch: High shelf, +2 dB or -2 dB from 8 kHz up

- Desk switch: -3 dB at 250 Hz and +4 dB at 1.2 kHz

- Calibration: Fully automatic and built-in digital calibration

- Full DSP control

- X-MONITOR macOS and Windows control software

- Total Latency (TOF): 3.00 ms

- Connectors: 1 x XLR balanced input, 1 x RCA unbalanced input, 1 x USB type-C, C8 power socket

- Power requirement: 90 to 240 V AC, auto-ranging, 50 or 60 Hz, 1 A max
