Specifications
·
Mfr Part Number: 11308-03-20G
·
GPU:
·AMD Radeon RX 6900 XT Graphics Card
·7nm GPU
·AMD RDNA 2 Architecture
·
Engine Clock:
·
€‹Boost Clock: Up to 2365 MHz
·
Game Clock: Up to 2135 MHz
- Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads
- Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary
·
Stream Processors: 5120
·
Infinity Cache: 128MB
·
Ray Accelerators: 80
·
Memory Size/Bus: 16GB GDDR6
·
Memory Clock: 16 Gbps Effective
·
Displays: Maximum 4 Displays
·
Resolution:
·
HDMI: 7680—4320
·
DisplayPort1.4: 7680—4320
·
Interface: PCI-Express 4.0
·
Output:
·1x HDMI
·3x DisplayPort
·
BIOS Support: Dual UEFI
·
Game Index: 4K
·
Sapphire Features:
·Dual BIOS
·Max Boost
·TriXX Software Switch
·Premium Digital Power Design
·Fuse Protection
·Tri-X Cooling Technology
·Intelligent Fan Control
·Precision Fan Control
·Backplate with ARGB
·ARGB Fans
·Two-Ball Bearing Fans
·Hybrid Fan Blade
·Wave Fin Design
·V Shape Fin Design for GPU Cooling
·Integrated Cooling Module
·K6.5 Memory Pad
·TriXX Supported
·Fan Check
·Fan Quick Connect
·TriXX Boost
·NITRO Glow
·External RGB LED MB Synchronization
·
AMD Features:
·AMD RDNA 2 Gaming Architecture
·DirectX 12 Ultimate
·Hardware Raytracing
·7nm GPU
·GDDR6 Memory
·PCI Express 4.0 Support
·AMD FreeSync Technology
·DisplayPort 1.4 with DSC
·HDMI
·Video Streaming up to 8K
·Radeon VR Ready Premium
·AMD FidelityFX
·Radeon Image Sharpening
·Radeon Anti-Lag
·Radeon Software
·Game Driver Optimizations
·High Performance 4K Gaming
·
Cooling: 3 Fans
·
Form Factor:
·2.7 slot, ATX
·Dimension: 310(L)X 134.3(W)X 55.3 (H)mm
·
Power Consumption: 363W
·
OS: Linux, Windows 7, Windows 10, and Windows 8.1. 64-bit operating system required
·
System Requirement:
·Minimum 850 Watt Power Supply
·2 x 8-pin + 1 x 6-pin Power Connector
·PCI Express based PC is required with one X16 lane graphics slot available on the motherboard
·Minimum 8GB of system memory. 16GB recommended
